Tohatsu MFS90A MID RANGE 4-Stroke 4 Cylinder OUTBOARD MOTOR

GST EXTRA & TRANSPORT EXTRA
SPECIFICATIONS
Engine 4 Cylinder
Output 90 ps (66.2 kw)
Displacement 1995 cc (121.6 cu.in.)
Bore x Stroke 84 x 90 mm (3.30 x 3.55 in)
Max. RPM Range 5,150 – 5,850
Starting Electric
Control Type Remote Control or Tiller Handle
Gear Shift Forward – Neutral – Reverse
Gear Ratio 2.08:1
Ignition System MicroComputer Programmed
Transom Height 20″
Fuel Unleaded Gasoline (87 Octane) or higher
Oil Type NMMA Certified FC-W® 4-stroke oil**
Oil Capacity 4.2 L (1.11 gal.) w/filter
Weight* 178 kg (392 lbs.)
Alternator Output 12V, 492W, 41A
Electronic Fuel Injection Standard
Start In Gear Protection Standard
Thermostat Controlled Cooling System Standard
Through-The-Prop Exhaust Standard
Overheat Buzzer Standard
Oil Pressure Warning Standard
Power Trim and Tilt Standard
Variable Idle Speed Standard

Tohatsu 90 hp 4-Stroke Benefits

  • Dynamic design with sophisticated details
  • Exhilarating boating performance
  • Superior durability & optimized weight
  • Outstanding fuel economy from unique SOHC-4V design
  • Performance-inspired engine sound and the most quiet at idle
  • Fine-tuned ECU Programming
  • Available in long (20”) shaft lengths

High Performance and Easy Operation

  • 4-2-1 Performance Tuned Exhaust generates high torque to get you on plane quicker
  • Fine-tuned ECU provides the strong acceleration when needed
  • Electronic Fuel Injection
  • MicroComputer Programmed ignition system for quicker starts
  • High output 41 amp alternator
  • New and improved gear case with wider splash plate and anti-ventilation plate
  • Adjustable steering friction and trim tab for reducing steering effort
  • Power Trim and Tilt

Fundamentals for User Convenience and Reliability

  • Sheet Molding Compound (SMC) cowlings for durability
  • Anodized major aluminum components for greater corrosion resistance
  • Oil catch tray underneath the oil filter for cleaner oil filter changes
  • Easily accessible and removable fuel filter allows simple and quick water draining
  • More than 16 sacrificial anodes strategically placed throughout all major components
  • Through the prop exhaust for a quieter operation
  • Built-in freshwater flushing system for easy routine flushing
  • Variable idling speed control from 650 to 850 RPMs at 5-steps
  • A camshaft-driven trochoid oil pump ensures long-term durability of critical engine components
  • Stainless steel water pump housing liner for outstanding durability

Warning & Protection

  • Low oil pressure warning (visual and audible)
  • Overheat warning (audible)
  • Start-in-gear protection for safer engine starting
  • Safety lanyard (an essential protection feature standard on all Tohatsu outboards)
  • Over-rev. limiter
